106 Functional description CG Drives & Automation 01-7492-01r1
Over volt [2524]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Under voltage [2525]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active
.
Over current F [2526]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Power Fault [2527]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active
.
Liquid cooling low level [2528]
Delay time starts counting when the fault disappears. When
the time delay has elapsed, the alarm will be reset if the
function is active.
Liquid Cooling Low level Trip Type [2529]
Select the preferred way to react to an alarm trip.
Motor protection [253]
Motor Lost [2531]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Locked Rotor [2532]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active
.
Motor I
2
t [2533]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active
.
2524 Over volt
Default: Off
Range: Off, 1–3600 s (Off=0)
2525 Under volt
Default: Off
Range: Off, 1–3600 s (Off=0)
2526 Over curr F
Default: Off
Range: Off, 1–3600 s (Off=0)
2527 Power Fault
Default: Off
Range: Off, 1–3600 s (Off=0)
2528 LC Level
Default: Off
Range: Off, 1–3600 s (Off=0)
2529 LC Level TT
Default: Trip
Trip 0 The motor will coast
Deceleration 1 The motor will decelerate
2531 Motor Lost
Default: Off
Range: Off, 1–3600 s (Off=0)
NOTE: Only visible when Motor Lost is selected in
menu [423].
2532 LockedRotor
Default: Off
Range: Off, 1–3600 s (Off=0)
2533 Motor I
2
t
Default: Off
Range: Off, 1–3600 s (Off=0)
