118 Functional description CG Drives & Automation 01-7492-01r1
Process Unit [322]
User-defined Unit [323]
This menu is only displayed if User is selected in menu
[322]. The function enables the user to define a unit with six
symbols. Use the Prev and Next key to move the cursor to
required position. Then use the + and - keys to scroll down
the character list. Confirm the character by moving the
cursor to the next position by pressing the Next key.
NOTE: The motor control method depends on the
selection of drive mode in menu [213], regardless of
selected process source in menu [321].
NOTE: If F (Bus) is chosen in menu [321] see 11.5.1
Analogue Inputs [510] on page 150.
322 Proc Unit
Default: Off
Off 0 No unit selection
% 1 Percent
°C 2 Degrees Centigrade
°F 3 Degrees Fahrenheit
bar 4 Bar
Pa 5 Pascal
Nm 6 Torque
Hz 7 Frequency
rpm 8 Revolutions per minute
m
3
/h 9 Cubic meters per hour
gal/h 10 Gallons per hour
ft
3
/h 11 Cubic feet per hour
User
Defined
12 User defined unit
NOTE: In case of conflicting setup between this
Process Source [321], selection and drive mode [213]
the software will automatically overrule the selection
in menu [321] according to the following:
[213]=Torque and [321]=Speed =>
internally [321]=Torque will be used.
[213]=Speed or V/Hz and [321]=Torque =>
internally [321]=Speed will be used.
Character
No. for serial
comm.
Character
No. for serial
comm.
Space 0 m 58
0–9 1–10 n 59
A11 ñ60
B12 o61
C13 ó 62
D14 ô63
E15 p64
F16q65
G17 r 66
H18 s 67
I19t68
J20u69
K21 ü70
L22v71
M23 w72
N24 x 73
O25 y 74
P26 z 75
Q27 å 76
R28 ä 77
S29 ö78
T30! 79
U31 ¨ 80
Ü32 #81
V33 $82
W34 %83
X35&84
Y36 · 85
Z37( 86
Å38 ) 87
Ä39 * 88
Ö40 + 89
a41, 90
á42- 91
b43. 92
