Emotron VFX 2.1 User Manual

236 Menu List CG Drives & Automation 01-7492-01r1
39M Run Time 6
31066 121/210 242A 1066 Long, 1=1h EInt
31067 121/211 242B 1067 Long, 1=1m EInt
31068 121/212 242C 1068 Long, 1=1s EInt
39M1 Rst Run Tm6 No 43 0/42 202B 43 UInt UInt
39N
Pump
123456
31069 121/213 242D 1069 UInt, 1=1 UInt
39P No of Backup 0 43177 169/81 4C69 19561 UInt, 1=1 UInt
3A0
Crane Option
[3A0]
3A1 Crane enable Off 43181 169/85 4C6D 19565 UInt UInt
3A2 Control 4-Speeds 43182 169/86 4C6E 19566 UInt UInt
3A3 Crane Relay1 No Trip 43183 169/87 4C6F 19567 UInt UInt
3A4 Crane Relay2 Brake 43184 169/88 4C70 19568 UInt UInt
3A5 PreLimSwSpd 100rpm 43185 169/89 4C71 19569 Int, 1=1rpm Int
3A6 CrawlSpd H/R 150rpm 43189 169/93 4C75 19573 Int, 1=1rpm Int
3A7 CrawlSpd L/L 150rpm 43190 169/94 4C76 19574 Int, 1=1rpm Int
3A8 Speed 2 600rpm 43186 169/90 4C72 19570 Int, 1=1rpm Int
3A9 Speed 3 1000rpm 43187 169/91 4C73 19571 Int, 1=1rpm Int
3AA Speed 4 1500rpm 43188 169/92 4C74 19572 Int, 1=1rpm Int
3AB Dev Bandwidt 100rpm 43191 169/95 4C77 19575 Int, 1=1rpm Int
3AC Dev Time 0.10s 43192 169/96 4C78 19576
Long,
1=0.001s
EInt
3AD LAFS Load Off 43193 169/97 4C79 19577 Long, 1=1% EInt
3AG Crane N Func Zero Pos 43194 169/98 4C7A 19578 UInt UInt
400
Load Monitor
and Process
Protection
[400]
410
Load Monitor
[410]
411 Alarm Select Off 43321 169/225 4CF9 19705 UInt UInt
412 Alarm trip Off 43322 169/226 4CFA 19706 UInt UInt
413 Ramp Alarm Off 43323 169/227 4CFB 19707 UInt UInt
414 Start Delay 2s 43324 169/228 4CFC 19708 Long, 1=1s EInt
415 Load Type Basic 43325 169/229 4CFD 19709 UInt UInt
416
Max Alarm
[416]
4161 MaxAlarmMar 15% 43326 169/230 4CFE 19710 Long, 1=1% EInt
4162 MaxAlarmDel 0,1s 43330 169/234 4D02 19714 Long, 1=0.1s EInt
417
Max Pre
Alarm [417]
4171 MaxPreAlMar 10% 43327 169/231 4CFF 19711 Long, 1=1% EInt
4172 MaxAlarmDel 0.1s 43331 169/235 4D03 19715 Long, 1=0.1s EInt
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
