Emotron VFX 2.1 User Manual

CG Drives & Automation 01-7492-01r1 Menu List 237
418
Min Pre Alarm
[418]
4181 MinPreAlMar 10% 43328 169/232 4D00 19712 Long, 1=1% EInt
4182 MinPreAlDel 0.1s 43332 169/236 4D04 19716 Long, 1=0.1s EInt
419
Min Alarm
[419]
4191 MinAlarmMar 15% 43329 169/233 4D01 19713 Long, 1=1% EInt
4192 MinAlarmDel 0.1s 43333 169/237 4D05 19717 Long, 1=0.1s EInt
41A Autoset Alrm No 43334 169/238 4D06 19718 UInt UInt
41B Normal Load 100% 43335 169/239 4D07 19719 Long, 1=1% EInt
41C
Load Curve
[41C]
41C1 Load Curve1 100%
43336 169/240 4D08 19720 Long, 1=1% EInt
43337 169/241 4D09 19721 Int, 1=1rpm Int
41C2 Load Curve 2 100%
43338 169/242 4D0A 19722 Long, 1=1% EInt
43339 169/243 4D0B 19723 Int, 1=1rpm Int
41C3 Load Curve 3 100%
43340 169/244 4D0C 19724 Long, 1=1% EInt
43341 169/245 4D0D 19725 Int, 1=1rpm Int
41C4 Load Curve 4 100%
43342 169/246 4D0E 19726 Long, 1=1% EInt
43343 169/247 4D0F 19727 Int, 1=1rpm Int
41C5 Load Curve 5 100%
43344 169/248 4D10 19728 Long, 1=1% EInt
43345 169/249 4D11 19729 Int, 1=1rpm Int
41C6 Load Curve 6 100%
43346 169/250 4D12 19730 Long, 1=1% EInt
43347 169/251 4D13 19731 Int, 1=1rpm Int
41C7 Load Curve 7 100%
43348 169/252 4D14 19732 Long, 1=1% EInt
43349 169/253 4D15 19733 Int, 1=1rpm Int
41C8 Load Curve 8 100%
43350 169/254 4D16 19734 Long, 1=1% EInt
43351 170/0 4D17 19735 Int, 1=1rpm Int
41C9 Load Curve 9 100%
43352 170/1 4D18 19736 Long, 1=1% EInt
43353 170/2 4D19 19737 Int, 1=1rpm Int
41D MinAbsMarg 3% 43354 170/3 4D1A 19738 Long, 1=1% EInt
420
Process
Protection
[420]
421 Low Volt OR On 43361 170/10 4D21 19745 UInt UInt
422 Rotor locked Off 43362 170/11 4D22 19746 UInt UInt
423 Motor Lost Off 43363 170/12 4D23 19747 UInt UInt
424 OverVolt Ctl On 43364 170/13 4D24 19748 UInt UInt
430 Trip Text
Menu Parameters
Default
settings
Modbus
Instance/
Device Net
No.
Profibus
slot/index
EtherCAT
index
(HEX)
Profinet
index
Fieldbus
format
Modbus
format
Notes
