Emotron VFX 2.1 User Manual

24 Mounting CG Drives & Automation 01-7492-01r1
Fig. 31 Emotron VFX Model 48-365-54 (Frame size FA).
Fig. 32 Cable interface for mains, motor, DC+/DC-, brake
resistor and communication, Emotron VFX Model 48-
365-54 (Frame size FA).
Fig. 33 Side view Emotron VFX Model 48-365-54 (Frame
size FA).
C
H
B
F
G
A
E
D
ø16 mm(x3)
(0.63 in)
ø9 mm(x6)
(0.35 in)
95 kg
(209 lb)
Cable glands M20
(x5)
(0.91 - 2.1 in)
Ø23-55 /M63
Cable flexible leadthrough
Table 12 Dimensions IP54 connected to fig. 31.
Frame
size
Emotron VFX
model
Dimension in mm (in)
A B C D E F
G
(depth)
H
FA 365
1065
(41.9)
1395
(54.9
300
(11.8)
17.5
(0.68)
10
(0.39)
345
(13.6)
365
(14.4)
150
(5.9)
