6 Commissioning PROline Prosonic Flow 93 PROFIBUS-DP/-PA
92 Endress+Hauser
“Wall thickness” measurement (only for Clamp On)
Procedure
Selection - Input - display
Local display (Quick Setup)
▼
FieldTool
▼
Commuwin II
▼
▼
 BASIC FUNCTION
 SENSOR DATA CH1/CH2
 SENSOR PARAM.
 BASIC FUNCTION
 SENSOR DATA CH1/CH2
 SENSOR PARAM.
Manufacturer-specific Transducer
Block “PROSONIC 93 PBUS”:
 SENSOR DATA (VAH5)
 SENSOR PARAM. CH1/CH2
Type of measurement MEASUREMENT (6880) MEASUREMENT MEASUREMENT
CH1 (V3H0) / CH2 (V6H0)
Sensor type SENSOR TYPE (6881) SENSOR TYPE SENSOR TYPE CH1 (V3H1)
SENSOR TYPE CH2 (V6H1)
▼
 BASIC FUNCTION
 PROCESS PARAM. CH1/CH2
 PIPE DATA
 BASIC FUNCTION
 PROCESS PARAM. CH1/CH2
 PIPE DATA
Manufacturer-specific Transducer
Block “PROSONIC 93 PBUS”:
 DE. MATRIX CH1/2 (VAH5)
 PIPE DATA CH1/CH2
Pipe material PIPE MATERIAL (6522) PIPE MATERIAL PIPE MATERIAL CH1/CH2 (V4H2)
Pipe sound velocity SOUND VELOCITY PIPE (6524) SOUND VELOCITY PIPE SOUND VELOC. PIPE CH1/CH2
(V4H4)
Wall thickness WALL THICKNESS (6527) WALL THICKNESS
 ADJUSTMENT/PIPE CH1/CH2
WALL THICKNESS CH1/CH2
(V4H7)
▼
Display of wall thickness WALL THICKNESS (6527) WALL THICKNESS
 PIPE DATA CH1/CH2
WALL THICKNESS CH1/CH2
(V4H7)
! Note:
• All functions are described in detail in the “Description of Device Functions” manual, which is a separate part of this
Operating Instruction!
• The procedure for running through the “Sensor Installation” Quick Setup using the local display is explained on Page 82.
