Endress+Hauser SpectraSensors SS500e User Manual

SS500e/SS2000e/SS3000e Gas Analyzer
1–16 4900002230 rev. D 2-6-20
Fuses are located on the electronics control board, as shown in Figure 1–6
through
Figure 1–11.
If you need to replace a fuse, use only the same type and rating
of fuse as the original as listed in Table 1–1.
Table 1–1 Fuse specifications
DWG Ref. Voltage Description Rating
F1
120 VAC Miniature Fuse, 5 x 20 mm, Time Delay 250VAC/0.8A
240 VAC Miniature Fuse, 5 x 20 mm, Time Delay 250VAC/0.5A
F2 24 VDC Miniature Fuse, 5 x 20 mm, Time Delay 250VAC/1.6A
NOTE: Refer to Figure 1–6 through Figure 1–11.
