3. Confirm that the relief valve vent line is properly installed from the
field pressure reducing station or the SCS to the low pressure flare
or atmospheric vent connection.
4. If applicable, confirm that the sample probe and field pressure
reducing station are properly traced and insulated without any
exposed surfaces.
5. If applicable, confirm that the field run electric-traced sample
transport tubing is installed correctly (no exposed tubing or
pockets), terminated properly at each end, and that each line has
been purged clean and pressure tested.
6. Confirm that all valves are closed and all switches are off.
7. Confirm that the AC power is available to the electrically traced
sample tubing (if applicable), analyzer, and SCS, but that the local
switches are off.
8. Confirm that the field analog and alarm signal wiring is
interconnected properly (see “Connecting the Output Signals
and Alarms” on page 3-11).
9. Confirm that the low pressure flare or atmospheric vent is properly
connected.
10. Confirm that the analyzer house atmospheric vent is properly
installed, if applicable.
11. Confirm that all sample system tubing has been thoroughly leak
checked.
Starting up the SCS
After the SCS installation has been thoroughly checked, you are ready to begin
preparing for initial SCS startup.
ToprepareforSCSstartup
1. Confirm that all AC power switches for the analyzer and SCS are off.
2. If applicable, apply AC power to the electric heat-traced sample
transport tubing at the tracer control system.
3. If applicable, confirm that the sample supply line electric heat tracer
temperature controller is set and that the sample supply line tracer
is heating to the appropriate temperature.
4. Confirm that the sample probe isolation valve is closed.
Personnel should have a thorough understanding of the operation
of the heat tracer power supply and control system, if applicable,
before operating the SCS.
