Table A–5 SS3000e H
2
O/CO
2
analyzer specifications
Performance
Concentration (H
2
O)
1
1. Consult factory for alternative ranges.
0.5–20 lbs/MMscf (0–422 ppmv)
0.5–50 lbs/MMscf (0-1055 ppmv)
0.5–100 lbs/MMscf (0-2110 ppmv)
Repeatability (H
2
O) ±0.2 lb/MMSCF (±4 ppmv) or±2% of reading
Concentration (CO
2
)
a
0–5%, 0-10%, 0-20%
Repeatability (CO
2
) ±400 ppmv or ± 2% of reading
Response time
2
2. Software adjustable.
0.25-2 seconds (dependent on flow rate and sample
system volume)
Application Data
Environmental Temperature Range -4 to 122 °F (-20 to 50 °C)
15 to 140 °F (-10 to 60 °C) - Optional
Environmental Relative Humidity Maximum of 95% relative humidity, non-condensing
Altitude Up to 4000 m
Maximum Cell Pressure 10 PSIG (70 kPaG)
Sample Cell Pressure Range 700-1400 mbara
700-1700 mbara - Optional
Sample Flow Rate 1–2 scfh (0.5–1.0 LPM)
Contaminant Sensitivity None for gas phase glycol, methanol, amines,
hydrogen sulfides or mercaptans.
Electrical & Communications
Input Voltages
3
3. Supply voltage not to exceed 10% of nominal. Transient over-voltages according to
Overvoltage Category II.
100–240 VAC, 50/60 Hz
18–24 VDC - Optional
Digital Outputs 2, General Fault and Assignable Alarm
Contact Rating (Inductive Load) AC-15 250V, 3 A NO contact, 1.5 A NC contact
DC-13 24V, 1 A NO contact and NC contact
Current (unheated) 1 A max @ 120 VAC, 1.6 A max @ 24 VDC
Current (optional condens. protection heater) 2 A max @ 120 VAC
Communication Analog: (2) 4–20mA Isolated, 1200 ohms @ 24 VDC
max load
Serial: RS-232C - Standard, RS-485 and Ethernet -
Optional
Protocol: Modbus Gould RTU, Daniel RTU or ASCII
LCD Display Concentration, cell pressure, temperature, alarms &
diagnostics
Physical Specifications
Size 42.3" H x 20" W x 11.06" D
(1074 mm H x 508 mm W x 281 mm D)
Weight Approximately 85 lbs (38.6 Kg)
Sample Cell Construction 316L Series Polished Stainless Steel
Certification
CSA Class I, Division 2, Groups B, C & D; Temp code T3C
(T3 with heaters)
