6. Remove the optical cable harness using a flat-head screwdriver.
7. Disconnect the cell inlet using a 9/16” wrench.
8. Disconnect the cell outlet using a 9/16” wrench.
9. Disconnect the thermistor cable at the circular connector.
10. Remove the pressure sensor cable from the circular connector inside
the enclosure.
For new model pressure sensors with quick-disconnects, detach the
pressure sensor cable from the pressure sensor at the connector
using a Phillips-head screwdriver. Do not remove the black connector
from the cable inside the enclosure.
11. Dismount the cell from the bracket by removing the four securing
screws (two on top, two on the bottom) using a 9-64” Allen wrench.
12. Place the measurement cell on a clean, flat surface with the pressure
sensor facing up. Refer to Figure B–5.
Figure B–4 SS500e/SS2000e SCS cabinet interior
CELL OUTLET
OPTICAL HEAD
PRESSURE
SENSOR/
CABLE
MOUNTING
BRACKETS
(behind cell)
CELL INLET
OPTICS CABLE
HARNESS
THERMISTOR
CABLE
