3
Section 1: Getting Started
In This Section
¾ Unpacking Your L24ex, L32 Ex Machine Or TT Machine
¾ Connecting The Computer
¾ Connecting The Exhaust
¾ Connecting The Electrical Power
¾ Laser Cooling Requirements And Operating Temperatures
Unpacking Your Machine
You will need to do the following to use your machine:
¾ Remove it from the crate
¾ Connect your computer
¾ Connect the exhaust system
¾ Connect power
¾ Configure your computer
You may need a contractor to install the exhaust (all models) and the 208-240 volts
(120 watt lasers only). This must be done PRIOR to the arrival of the Epilog
installation technician.
Unpacking Your L24EX or L32EX Machine
1. Cut and remove the strapping around the box and the plywood top. Remove the
plywood top.
2. Cut the tape on the top of the box. Open the flaps and remove as much packing
as you can. Please save this packing material. This includes the foam top
supports and four wood and foam corner supports.
3. Remove eight (8) Phillips head screws (w/ large washers) located around the
base of the corrugated box.
4. With a friend, lift the box up over the machine. PLEASE do not throw away the
box, you may need it later. Remove the plastic bag over the machine.
5. On the pallet (the wooden platform the machine is sitting on) locate the edge
that is secured with two screws. Loosen and remove the screws, and remove
the wooden 2”x2”.
