Section 7: Using the Epilog Legend Print
Driver
70
Additional stamp setup and guidelines are explained in Section 11, Material
Engraving Techniques of this Manual.
More Options
Computer Controlled Speed/Power
When this box has a “Yes” in it, the Speed and Power settings are controlled from
the computer. If this box has a “No” in it, the Legend will use the settings on the
LCD control panel of the engraver as set from the “Setup” menu heading.
Auto Focus
A “Yes” will enable the auto focus, “No” will disable auto focus.
Note: “Important note about Auto Focus!” When a job is started and auto
focus has been enabled the carriage will move to the first point of engraving (or
cutting) then the table will automatically move up until the auto focus plunger
is activated. If the first point of engraving is in the middle of the table, the
carriage will move to that point before focusing!! The auto focus plunger must
clear all edges of the work piece before focusing or it may cause damage.
Please be careful when auto focusing on irregularly shaped items.
Configuration
The “Configuration” box allows you to save all of your laser settings in the
“Legend Engraver EX Win32 Printing Preferences” window as a custom setup.
First, select the desired settings (Speed, Power, Piece Size, etc) for a particular job
in the Printing Preferences setup window. Next, to save these settings and
identify them with a name, click the cursor in the Configuration box, then select
“Save As…” The “Save As…” box will bring up the “Save Configuration Data
