Section 17: Specifications
193
Legend 32EX Specifications
Maximum Engraving Area 32" x 20" (812 x 508 mm)
Maximum Material Thickness 9" (228 mm)
Table Size 37" x 21" (940 x 533 mm)
Laser Control Display Panel 4" x 3" LCD displays job graphic, stored file names, speed, power,
run time, and more. Drop down menus provide user control of all
laser settings, calibration, and special features.
Intelligent Memory Buffer Store unlimited files up to 32 MB. Rolling buffer allows files of
any size (32 MB and larger) to be engraved.
Operating Modes Optimized raster engraving, vector cutting, or combined
raster/vector mode.
Motion Control High speed, continuous loop, DC servomotors using linear
encoding technology for precise positioning.
Laser Source State-of-the-art, digitally controlled, air-cooled CO2 laser tubes are
fully modular, permanently aligned, and field
replaceable/upgradeable.
Bearings Ground and polished steel NeverWearTM bearing system.
Belts Advanced B-style doublewide Kevlar precision drive belts.
Resolution User controlled choice of 150, 200, 300, 400, 600, or 1200 dpi.
Speed/Power Control Computer or machine controlled Speed and Power in 1%
increments to 100%. Vector color mapping links Speed and Power
setting to any RGB color.
Print Interface 10 Base T Ethernet or Parallel connections. Compatible with
Windows XP/2000.
Standard Features Red Dot Pointer, Air Assist (pump optional), Auto Focus, 2" focus
lens, relocatable home, flash upgrade electronics.
Size/Weight 42" wide x 32.5" deep x 42" high (1067 x 826 x 1067 mm) 375 lbs
(172 kg) - 120 watt cabinet is 34.5" deep (876 mm)
Electrical Requirements Auto-switching power supply accommodates 110 to 240 volt, 50 or
60 Hz, single phase, 15 amp AC.
Exhaust Ventilation External exhaust to the outside required. Output diameter at
machine is 6".
Safety CDRH Class IIIa
Max Ambient Room Air Temperature 90 degrees F (32 C) Max
