Section 1: Getting Started
14
Never run a job on a Legend TT unless the exhaust blower is hooked up and
operating properly!
Exhaust blower plugged into the
switched outlet on the TT.
To the outside
Blower
The exhaust blower pulls ambient room air
through the front of the TT and over the
cooling fins of the laser. This air cools the
laser tube when a job is running and evacuates
the engraving cavity of smoke and debris
Air flow in.
