Epson Artisan 700 / Epson Stylus Photo PX700W / TX700W Revision C
PRODUCT DESCRIPTION Control Panel 27
Confidential
1.6.2 Control Panel Functions in Each Mode
1.6.2.1 Control Panel Functions
The table below shows the print setting menu items for each mode and their defaults,
and when the settings are saved or returned to their defaults. Explanations on detailed
control panel functions of the Artisan 700/Epson Stylus Photo PX700W/TX700W
are omitted
here, because the LCD displays the detailed instruction.
Table 1-23. Button Functions
(Epson Artisan 700/Epson Stylus Photo PX700W/TX700W)
Button Function
Power
Turns the power ON/OFF.
Display/Crop
• Goes to the zoom setting screen for the selected image.
• Changes the image preview layout on the LCD.
-, + Sets pages to print
Unlock Release the lock of the Control Panel.
Start Starts printing.
Stop/Clear Settings
• Stops operation and displays the menu screen.
• Stops printing and ejects paper.
• Returns the print settings in the current mode to th
eir defaults
and displays the Top screen. (Returns to the previous screen
during printing maintaining the current settings)
Back Cancels the previous operation.
Cross Key/OK
• Selects a menu item or a setting value.
• Accepts the changed settings
Menu Goes to the menu screen for each mode.
Auto Correct Changes the Auto Correct ON/OFF.
Print Tray Ejects/retracts the CDR Tray.
Mode
Changes modes in the following order.
Copy/Photos/Scan/Backu
p Data/Print Ruled Papers/Setup/
Problem Solver/FAX
Table 1-24. LED
LED Function
Power (Green)
• Flashes while powering ON/OFF.
• Flashes during some sequence is in progress.
• Flashes when a fatal/maintenance error occurs.
• Lights when the status is other than above.
(Stand by mode/during setting
on the Panel, etc.)
Blue status light Flashes or lights according to the printer status.
Table 1-25. Timing of Saving or Initializing Control Panel Settings
Mode Print Setting Default Value
Copy Normal Copy Copy Type Color
Density
±0
Layout With Border
2-Sided Printing Off
Reduce/Enlarge Actual
Paper Size
• EAI: Letter
• Euro/Asia: A4
Paper Type Plain Paper
Document Type Text & Image
Quality Standard Quality
Expansion Standard
Dry Time Standard
Binding Direction Vertical-Short
To Next Page
