2.7.2 AC Power Cable
WARNING
■
Be sure to connect the AC power cable to a power receptacle. DO
NOT connect it directly to a factory power source. To shut off
power to the robot system, pull out the power plug from the power
source.
Performing any work while connecting the AC power
cable to a factory power source is extremely hazardous and may
result in electric shock and/or malfunction of the robot system
■
Make sure that cable manufacturing and connection are done by
a qualified
personal.
When proceeding, b
e sure
to connect the earth wire of the AC
power cable colored green/yellow
on the Controller to the earth
terminal of the factory power supply. The equipment must be
grounded properly at all times to avoid the risk of electric
shock.
Always use a power plug
and receptacle for power connecting
cable
. Never connect the Controller directly to the factory power
supply.
(Field wiring)
The AC plug is the optional part.
Attach a proper plug to the cable that is suitable for the factory power supply.
Connection Specification of Cable Wire
Purpose
Color
AC power wire (2 cables)
Black
Ground wire
Green / Yellow
Specification of Power plug (option)
Name
Model
Manufacturer
AC plug
4222R
AMERICAN DENKI
Cable length: 3 m (Standard)
