SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 196
Confidential
Connector assignment:
Connector
assignment:
Color Destination
CN1
White TAKE-UP REEL PS BOARD (CN2)
CN2*
White Unused
CN3
-USB-A
CN4*
-Unused
CN7*
Black Unused
CN8*
Blue Unused
CN10*
Yellow Unused
CN11*
Black Unused
CN14*
Blue Unused
CN15*
Red Unused
CN17
White TAKE-UP REEL SWITCH
CN18
Black TAKE-UP REEL MOTOR
CN19*
Black Unused
CN22
Yellow TAKE-UP REEL MOTOR
CN23
Black TAKE-UP REEL LED
CN24*
(FFC) Unused
CN26*
Red Unused
CN28
Red TAKE-UP REEL SENSOR
CN29
White TAKE-UP REEL SENSOR
