Epson SC-T7000 series User Manual

SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT Overview 206
Confidential
Board
related
parts/units
Main Board (NVRAM backup
OK & HDD none)
*1
After
replacement
11
Main Board initial setting (automatically
power off)
√√---
p. 270
12
Firmware update mode ON --- √ ---
13
NVRAM Backup tool (Write) √√---
p. 221
14
Turn the power off. --- √ ---
15
Print Cover Close √√---
16
Turn the power on in normal mode. --- √ ---
17
Install ink cartridges --- √ ---
18
Model Selection (at service program) √√---
19
RTC & USB ID Input √√---
p. 271
20
Reset the Main Board exchange counter. √√---
p. 275
21
Housing Assembly --- √√
Main Board (NVRAM backup
NG & HDD none)
*1
Before
replacement
1
Print Cover Open --- √ ---
2
Remove ink cartridges --- √ ---
Replacement
3
---
p. 111
After
replacement
4
Turn the power on in Firmware update mode. --- √ ---
5
Model Selection (at service program) √√---
6
Update the firmware.
*2
(automatically power
off)
√√---
p. 229
7
Turn the power on in Serviceman mode. --- √ ---
8
NVRAM Clear OK --- √ ---
9
Main Board initial setting (automatically
power off)
√√---
p. 270
10
Serviceman Mode ON --- √ ---
11
Initial Ink Charge Flag √√---
p. 233
12
Rear AD Adjustment √√---
p. 269
13
Head ID Input(automatically power off) √√---
p. 249
14
Turn the power on in Serviceman mode. √√---
15
RTC & USB ID Input √√---
p. 271
16
Model Selection (at service program) √√---
17
MAC Address Input √√---
p. 272
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired (Reattached)
Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
