Epson SC-T7000 series User Manual

SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT Overview 205
Confidential
Paper feed
related
parts/units
PF MOTOR
After
replacement
5
Media Feed Auto Adjustment √√---
p. 265
6
PW + T&B&S check and adjustment √
Matte paper
√ ---
p. 243
7
Cut Position Check & Adjustment √√---
p. 266
8
Reset the motor counter. √√---
p. 231
PF ENCODER
Replacement
1
---
p. 166
After
replacement
2
Turn the power on in normal mode. --- √√
3
PC Scale Check √√√
p. 264
CUTTER UNIT (cutter motor)
Replacement
1
---
p. 181
After
replacement
2
Turn the power on in normal mode. √√---
3
Cutter motor measurement √√---
p. 279
4
Cut Position Check & Adjustment √√---
p. 266
5
Reset the motor counter. √√---
p. 231
ATC MOTOR
Replacement
1
---
p. 175
After
replacement
2
Turn the power on in normal mode. --- √ ---
3
ATC Motor Measurement √√---
p. 279
4
Reset the motor counter. √√---
p. 231
PAPER THICKNESS SENSOR
Replacement
1
---
p. 180
After
replacement
2
Paper thickness sensor adjustment ---
Adjustment jig for
paper thickness sensor
√√
p. 267
Board
related
parts/units
Main Board (NVRAM backup
OK & HDD none)
*1
Before
replacement
1
Print Cover Open √√---
2
Remove ink cartridges --- √ ---
3
Turn the power on in Serviceman mode. √√---
4
NVRAM Backup tool (Read) √√---
p. 221
Replacement
5
---
p. 111
After
replacement
6
Turn the power on in Firmware update mode. --- √ ---
7
Model Selection (at service program) √√---
8
Update the firmware.
*2
(automatically power
off)
√√---
p. 229
9
Turn the power on in Serviceman mode. --- √ ---
10
NVRAM Clear OK --- √ ---
Table 4-1. Adjustment items and the order by repaired part
