Epson SC-T7000 series User Manual

SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT Overview 204
Confidential
Ink supply
related
parts/units
DAMPER KIT
Before
replacement
1
Turn the power on in normal mode. --- √√
2
Tube inner pressure reduction √√√
p. 248
3
Auto CR unlock & move CR to full column
side
√√√
Replacement
4
---
p. 123
After
replacement
5
Turn the power on in normal mode. --- √√
6
Set paper. --- √√
7
Cleaning √√√
p. 252
8
Nozzle Check √
PGPP
√√
p. 251
9
Cleaning √√√
p. 252
10
Reset the damper kit counter. √√---
p. 231
11
CR cover assembly --- √√
12
Housing Assembly --- √√
Paper feed
related
parts/units
PF TIMING BELT
Replacement
1
---
p. 168
After
replacement
2
Turn the power on in normal mode. --- √√
3
PF Belt Tension check √
Tensimeter U-507
√√
p. 262
4
PF Motor Measurement & Automatic
Adjustment
√√---
p. 279
5
Media Feed Auto Adjustment √√---
p. 265
6
PW + T&B&S check and adjustment √
Matte paper
√ ---
p. 243
7
Cut Position Check & Adjustment √√---
p. 266
PF MOTOR
Replacement
1
---
p. 163
After
replacement
2
Turn the power on in normal mode. --- √ ---
3
PF Belt Tension check √
Tensimeter U-507
√√
p. 262
4
PF Motor Measurement & Automatic
Adjustment
√√---
p. 279
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired (Reattached)
Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
