Epson SC-T7000 series User Manual

SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
ADJUSTMENT Overview 210
Confidential
Board
related
parts/units
Main Board (NVRAM backup
NG & HDD exist)
*1
After
replacement
37
Auto Bi-D adjustment, acceleration and
deceleration correction
√
PGPP
√ ---
p. 242
38
PW + T&B&S check and adjustment √
Matte paper
√ ---
p. 243
39
CUT Motor Measurement √√---
p. 279
40
Cut Position check & adjustment √√---
p. 266
41
Reset the Main Board exchange counter. √√---
p. 275
MAIN-C BOARD (Network
Board)
Replacement
1
---
p. 111
After
replacement
2
Turn the power on in Firmware update mode. --- √ ---
3
Update the firmware.
*2
√√---
p. 229
4
Turn the power on in Serviceman mode. --- √ ---
5
MAC Address Input √√---
p. 272
6
Housing Assembly --- √√
PSH BOARD (Power Supply
Board)
Replacement
1
---
p. 118
After
replacement
2
Turn the power on in normal mode. --- √ ---
3
CR Motor Measurement & Automatic
Adjustment
√√---
p. 279
4
PF Motor Measurement & Automatic
Adjustment
√√---
p. 279
5
Pump Cap Unit Measurement & Automatic
Adjustment
√√---
p. 279
6
CUT Motor Measurement √√---
p. 279
7
Make the replacement date & time setting. √√---
p. 275
8
ATC Motor Measurement √√---
p. 279
9
Housing Assembly --- √√
Others SUCTION FAN
Replacement
1
---
p. 184
After
replacement
2
Suction Fan Adjustment √√---
p. 276
Table 4-1. Adjustment items and the order by repaired part
Class
Replaced or Repaired (Reattached)
Part/Unit
Required Operations
Service
Program
Jig Media Replaced Reattached Page
