APPENDIX Connection Diagram 298
Confidential
Cable No. Connection
1
PANEL BOARD MAIN-C BOARD (CN4)
2
PANEL BOARD MAIN BOARD(CN13)
3
PAPER THICKNESS SENSOR
Relay Cable
(MAIN BOARD (CN16))
4
APG MOTOR MAIN BOARD (CN15)
5
CR MOTOR MAIN BOARD (CN19)
6
CR HP SENSOR
Relay Cable
(MAIN BOARD (CN16))
7
PE SENSOR (ROLL PAPER)
Relay Cable
(MAIN BOARD (CN17))
8
ATC MOTOR MAIN BOARD (CN15)
9
SUB-B BOARD MAIN BOARD (CN300)
PANEL BOARD MAIN-C BOARD (CN4)
Relay Cable
(CUTTER SENSOR)
MAIN BOARD (CN16)
Relay Cable
(PE SENSOR (ROLL PAPER))
MAIN BOARD (CN17)
Relay Cable
(CR HP SENSOR)
MAIN BOARD (CN16)
Relay Cable
(PAPER THICKNESS SENSOR)
MAIN BOARD (CN16)
10
APG MOTOR MAIN BOARD (CN15)
ATC MOTOR MAIN BOARD (CN15)
Relay Cable
(SUCTION FAN (Left))
MAIN BOARD (CN23)
Relay Cable
(SUCTION FAN (Right))
MAIN BOARD (CN22)
INTERLOCK SWITCH MAIN BOARD (CN20)
Relay Cable (CR HP SENSOR) MAIN BOARD (CN16)
Relay Cable (CUTTER SENSOR) MAIN BOARD (CN16)
11
HEAD FFC MAIN BOARD (CN101/CN102)
CR FFC MAIN BOARD (CN100)
12
Relay Cable
(PUMP CAP UNIT / IC HOLDER)
MAIN BOARD (CN14)
13
SUB-B BOARD MAIN BOARD (CN301)
PE SENSOR (THICK PAPER) MAIN BOARD (CN21)
Cable No. Connection
