SC-T7000 series/SC-T5000 series/SC-T3000 series Revision B
APPENDIX Connection Diagram 301
Confidential
 Back view (Right rear) (4)
1
2
3
Cable No. Connection
1
PE SENSOR (ROLL PAPER)
Relay Cable
(MAIN BOARD (CN17))
2
SUB-B BOARD MAIN BOARD (CN301)
3
SUB-B BOARD MAIN BOARD (CN300)
