Epson TM-U200 Series Technical Manual

Rev. A Troubleshooting 4-15
TM-U200 Series (Type A/AM) Technical Manual
Confidential
The print color is
mixed. (Half of
the character is
black and the
other half is red.)
The ribbon cassette is
floating.
A Verify that the ribbon cassette
is mounted correctly.
Mount the ribbon cassette
in the correct position.
(See “Replacing the
Ribbon Cassette” in
Chapter 3.)
The ribbon is placed
incorrectly.
A Verify that the ribbon is not
placed between the print
head mask assembly and
paper feed frame assembly.
Place the ribbon between
the print head unit and
print head mask assembly.
The ribbon frame
assembly is deformed.
B Verify that the ribbon frame
assembly is not deformed.
If deformed, replace the
ribbon frame assembly.
The ribbon is
defective.
A Verify that the color of the
ribbon is not blurred, or the
ribbon is not rumpled or worm
Replace the ribbon
cassette if the ribbon is
worn or the print color is
light.
Color does not
change. (Black
to red or red to
black.)
The ribbon release
spring is unhooked or
damaged.
B Verify that the ribbon release
spring is not unhooked or
damaged.
If the spring is unhooked,
hook it back on. If it is
damaged, replace it.
The ribbon frame
spring is unhooked or
damaged.
B Verify that the ribbon frame
spring is not unhooked or
damaged.
If the spring is unhooked,
hook it back on. If it
damaged, replace it.
Table 4-2 Troubleshooting table for bad printing (Continued)
Problem Probable cause Level Checkpoint Action
