Rev. A
Di
sassembly, Assembly, and Adjustment
5-23
TM-U200 Series (Type A/
AM) Technical Manual
Co
nf
i
d
en
t
i
al
Main Assembly 8
Carriage guide shaft assembly
1.
Insert
the carriage g
uide shaft th
rough the ba
se frame assembly
and carriage su
b assembly
and lo
ck it w
ith
the R
E.
Carriag
e guide shaft
Base frame
assembly
RE (2.3)
Carriage sub assem
bly
132
