Hardware Configuration
Figure 1-6 TM-U200 Series (Type A/AM) main unit configuration
Carriage motor
Paper feed motor
Paper end detector
Print head unit
Home position sensor
Paper roll near-end detector (optional)
Main circuit board
Interface circuit board
