Buttons and Switches
Power Switch
Note:
Turn on the power only after connecting the power supply.
Panel Button
The panel button is enabled or disabled by the
ESC c 5
command. This button is inactive if it is
disabled.
Note:
The
E
EE
ES
SS
SC
C C
C c
c c
c 5
55
5
command enables or disables the panel button. When disabled, the button does not function.
However, when loading a paper roll, you can feed paper with the
FEED
button during the paper loading
waiting time if the paper loading waiting time is set by
G
GG
GS
S S
S z
z z
z 0
00
0
. Press the
FEED
button again after the
PAPER OUT LED
starts blinking to return the printer to the on-line state.
DIP Switches
Serial interface (RS-232 and RS-485 (option))
The DIP switches are located at the bottom of the case.
Type: Rocker switch
Function: The power switch turns the power on or off.
Feed
(FEED
) button: Type: Non-locking push button
Function: Feeds paper based on the line feed amount set by
ESC 2
and
ESC 3
.
DIP switch 1
DIP Switch Function ON OFF
1 Data receive error Ignored Prints “?”
2 Receive buffer capacity Data buffer 40 bytes Data buffer 1000 bytes (Type A)
Data buffer 512 bytes (Type
AM)
3 Handshaking XON/XOFF DTR/DSR
4 Data word length 7 bits 8 bits
5 Parity check Yes No
6 Parity selection Even Odd
7 Baud rate selection 4800 bps 9600 bps
8 Busy condition When the receive buffer is full When the receive buffer is full in
off-line status
