Rev. A Features and General Specifications 1-17
TM-U200 Series (Type A/AM) Technical Manual
Confidential
Interface
RS-232 Serial Interface
Notes:
❏
Handshaking, data word length, baud rate, and parity depend on DIP switch settings.
❏
Data transmitted from the printer has 1 stop bit (fixed).
Data transmission: Serial (compatible with RS-232)
Synchronization: Asynchronous
Handshaking: DTR/DSR or XON/XOFF control
Signal levels: MARK = -3 to -15 V: Logic 1/OFF
SPACE = +3 to +15 V: Logic 0/ON
Baud rates: 4800, 9600 bps
Data word length: 7 or 8 bits
Parity settings: None, even, odd
Stop bits: 1 or more
Connector: Female D-SUB 25-pin connector or equivalent
