1-16 Features and General Specifications Rev. A
Confidential
Notes:
❏
Two driver transistors cannot be energized simultaneously.
❏
The drawer drive duty must be as shown below:
❏
Be sure to use the printer power supply (connector pin 4) for the drawer power source.
CAUTION:
Do not connect a telephone line to the drawer kick-out connector; otherwise the printer
and the telephone line may be damaged.
ON time
(ON time + OFF time)
≤
0.2
