External Dimensions and Weight
Environmental Specifications
Figure 1-5 Operating temperature and humidity range
Height: With cover closed: 160 mm (6.30")
With cover opened: 355 mm (13.87”)
Width: 160 mm (6.30")
Depth: 295 mm (11.60")
Weight: Approximately 2.5 kg (5.5 lb)
Color: EPSON standard color
Temperature: Operating: 5° to 35° C (41° to 95° F)
Storage: –10° to 50° C (14° to 122° F), except paper and ribbon
Humidity: Operating: 10% to 90% RH (non-condensing)
Storage: 10% to 90% RH (non-condensing), except paper and ribbon
Vibration resistance: When packed:
Frequency: 5 to 55 Hz
Acceleration: 2 G
Sweep: 10 minutes (half cycle)
Duration: 1 hour
Directions: x, y, and z
Operating Temperature Range
40° C (104° F), 65%
34° C (93° F), 90%
50° C (122° F), 35%
80
60
40
20
0
0
10 20 30
40
Environmental Temperature
Relative Humidity [% RH]
50
90
10
