Main Unit Specifications
Paper Feed Motor
Carriage Motor
Print Head Unit
Home Position Sensor
Type: 4-phase, 48-polarity, PM-type stepping motor
Drive voltage: 24 VDC ± 10%
Winding resistance: 39.5 Ω ± 5 Ω at 25° C (77° F), per phase
Current consumption: Peak: 1.5 A in worst case
Average: 400 mA at 24 VDC, 25° C (77° F), 600 pps
600 mA maximum
Type: 4-phase, 48-polarity, PM-type stepping motor
Drive voltage: 24 VDC ± 10%
Winding resistance: 39.5 Ω ± 1.9 Ω at 25° C (77° F), per phase
Current consumption: Peak: 1.5 A maximum
Average: 400 mA at 24 VDC, 25° C (77° F), 952 pps
600 mA maximum
Number of solenoids: 9
Winding resistance: 19.2 Ω ± 5% at 25° C (77° F), per phase
Drive voltage: 24 VDC ± 10%
Type: Photo sensor
Voltage: 5 VDC ± 5%
Output level: LOW when the carriage home position is detected
