TM-U200 Series (Type A/AM) Technical Manual
Confidential
Chapter 5
Disassembly, Assembly, and Adjustment
Small Part Specifications
This section uses abbreviations for small parts, such as screws and washers. The following is a
list of these abbreviations and illustrations of the screw types.
❏ CCS-tite Cross-recessed Cup head S-tite self-tapping screw
❏ CBS-tite Cross-recessed Binding head S-tite self-tapping screw
❏ CBB-tite Cross-recessed Binding head B-tite self-tapping screw
❏ CBT-B Cross-recessed Binding head self-tapping screw not fluted class 2
❏ CP(O) Cross-recessed Pan head screw with outside toothed lock washer
❏ CPS-tite Cross-recessed Path head S-tite self-tapping screw
❏ CPS-tite(O) Cross-recessed Pan head S-tite screw with outside toothed lock washer
❏ CPS-tite(S-P4) Cross-recessed Pan head S-tite self-tapping screw with Spring lock washer
and plain washer
❏ CPT-B Cross-recessed Pan head self-tapping screw not fluted class 2
❏ CPP-tite Cross-recessed Pan head P-tite self-tapping screw
Head (top) Head (side) Body Washer (assembled)
C (Cross) P (Pan)
B (Bind)
C (Cup)
S-tite
T-B
B-tite
P-tite
(O)
