Epson TM-U200 Series Technical Manual

Rev. A Features and General Specifications 1-3
TM-U200 Series (Type A/AM) Technical Manual
Confidential
Note:
If the print duty ratio is too high, the operation of the print head is stopped by the duty limit. In such
circumstances, the print speeds shown above cannot be guaranteed.
cpi = characters per inch.
*1) This value can be changed by command.
*2) Type AM only.
Note:
The default font is 7 x 9; the dot spacing between characters is either 3 half dots or 2 half dots, depending
on the setting of DIP switch 2-1.
Character dimensions, characters per inch, characters per line
Character Structure
Horizontal x Vertical
Character
Structure
Character Set
Character
Dimensions
WxH
Dot Spacing
Between
Characters
Characters Per
Line (cpl)
Characters Per
Inch (cpi)
7 x 9 ANK 1.2 x 3.1 mm
(.047 x .122")
3 half dots 40 16
Graphics 1.7 x 3.1 mm
(.070 x .122")
04016
9 x 9 ANK 1.6 x 3.1 mm
(.063 x .122")
3 half dots 33 13.3
Graphics 2.0 x 3.1 mm
(.079 x .122")
03313.3
7 x 9 ANK 1.2 x 3.1 mm
(.047 x .122")
2 half dots 42 17.8
Graphics 1.6 x 3.1 mm
(.063 x .122")
04217.8
9 x 9 ANK 1.6 x 3.1 mm
(.063 x .122")
2 half dots 35 14.5
Graphics 1.9 x 3.1 mm
(.075 x .122")
03514.5
16x 16 *2) Kanji 2.7 x 2.7 mm 0 25 9.5
(.106 x .106”) 2 22 *1) 8.9
