3-12 Handling and Maintenance Rev. A
Confidential
9. Remove the print head cover.
10. Remove all the jammed paper.
Note:
Do not pull the jammed paper in the opposite direction of paper feeding.
11. Replace the print head cover and secure it with the screw.
12. Replace the ribbon cassette and close the auto cutter.
13. If the auto cutter blade is not in its normal position (if you can see the blade in the auto cutter
slit, the blade is not in the normal position), insert a screwdriver into the right side of the
auto cutter and turn the gear inside to move the blade to the normal position.
14. Replace the paper roll and close the printer cover.
To Next Page
