8 • Actuation Configurations for ICC 200
2
Plug HF cable 20192-082 or 20192-126 into HF input of the APC
300 and into the CUT / COAG socket of the ICC.
If an instrument, rather than the HF cable, is connected to the CUT /
COAG socket, you can actuate this instrument using the foot switch!
2. Connect HF cable
WARNING!
3. Connect neutral electrode
Position the neutral electrode on the patient. Connect neutral electrode
to the ICC.
of equipment trolley.
ICC and APC 300.
1. Open the cylinder valves on the argon gas cylinders in a clockwise
direction until they stop.
4. Plug in mains plug
5. Switch on
6. Open cylinder valves
