Actuation Configurations for ICC 200 • 8
7
1. Screw the bacteriological filter to the argon socket.
2. Screw the argon connection
to the filter.
3. Plug in the cable's multiple plug
to the APC 300's multiple socket.
Is the automatic setting of the COAG flow / CUT flow suitable for the
application?
Press PUR key and rinse the applicator with argon.
Press the blue pedal or the blue finger switch.
Press the yellow pedal or the yellow finger switch.
12. Actuate the APC
9. Connect the APC handle
10. Check flow
11. Rinse applicator
13. Actuate ARGON CUT
