8 • Actuation Configurations for ICC 300
10
Position neutral electrode on the patient. Connect the neutral electrode
to the ICC 300.
of equipment trolley.
ICC 300 and APC 300.
1. Open the cylinder valves on the argon gas cylinders in a clockwise
direction until they stop.
2. Check fill level of the argon cylinders (fill level of the argon cylinders
is in the information line of the standard display). Always keep a full
replacement cylinder at the ready.
1. Set AUTO COAG field to SPRAY. Displayed: 60 (power limit 60 W)
2. Select the desired power limit.
3. Position P
EDAL key to AUTO COAG field. Imperative!
3. Connect neutral electrode
4. Plug in mains plug
5. Switch on
6. Open cylinder valves
7. Set ICC for APC
WARNING!
