8 • Actuation Configurations for ICC 350
22
1. Position neutral electrode on the patient. Connect the neutral electrode
to the ICC 350.
2. Plug HF plug of the electrode handle
into the CUT / COAG 1 socket.
3. Connect bipolar instrument to the BIPOLAR socket of the ICC 350.
of the equipment trolley.
ICC 350 and APC 300.
1. Open the cylinder valves on the argon gas cylinders in a clockwise
direction until they stop.
2. Check fill level of the argon cylinders (fill level of the argon cylinders
is in the information line of the standard display). Always
keep a full replacement cylinder at the ready.
1. Set AUTO COAG 2 to SPRAY. Displayed: 60 (power limit 60 W).
2. Select the desired power limit.
Select effect and power limit in AUTO CUT field.
Position P
EDAL key to AUTO COAG 2 field. Imperative!
Select a power limit in the AUTO BIPOLAR field. Select an AUTO START
mode, or actuate using the white single-pedal foot switch.
3. Connect instruments, neutral
electrode to ICC 350
9. P
EDAL key
10. Set ICC for BIPOLAR COAG
WARNING!
4. Plug in mains plug
5. Switch on
6. Open cylinder valves
7. Set ICC 350 for APC
8. Set ICC 350 for ARGON CUT
