8 CONFIGURATION MENU
0460 949 274
- 49 -
© ESAB AB 2015
Example, I/O OFF
Welding head 2 (slave)
TAIL
Welding head 1 (master)
HEAD
WELD HEAD OFFSET
•
Press Start, for welding head1 and welding head2 at the same time.
• Welding head1 starts to weld.
• Welding head2 starts to weld first when the start position for welding head1 has been
reached (the distance given WELD HEAD OFFSET).
•
Press stop, for welding head1 and welding head2 at the same time.
• Welding head1 stops welding but travel motion continues.
• Welding head2 stops welding when it has reached the point where equipment1 stopped
welding (the distance that is given in WELD HEAD OFFSET).
• Welding is complete.
