ESAB DTE 255 - Page 80

DTE 255
Edition 040621
-- 2 --
dpb1s
C = component designation in the circuit diagram
Item Qty Ordering no. Denomination Notes C
101 4 0192 296 104 Knob
102 7 0191 508 102 Knob
103 2 0192 296 102 Knob
104 1 0468 543 882 Handle
105 1 0468 529 001 Rubber mat
106 4 0365 534 001 Sealing washer
107 1 0301 015 001 Cover When the cover is replaced, items 108 and 134 must
also be replaced
108 10 0192 859 006 Locking washer Must be pressed with 50 kg pressure when fitted.
109 1 0301 021 001 Rear plate
110 1 0301 028 001 Grill
111 1 0301 054 001 Filter
112 1 0301 027 001 Grill
113 3 0441 819 001 Screw
114 1 0301 053 001 Filter
115 1 0457 817 881 Capacitor 47 nF, 275 V AC, with cable lugs C06
116 1 0457 817 880 Capacitor 47 nF, 1000 V AC, with cable lugs C07
117 1 0367 258 880 Central connection For machines with central TIG connection XS12
118 0190 209 114 Hose To be ordered per metre
119 1 0252 103 501 Hose nipple For machines with OKC TIG connection
120 1 0156 868 880 OKC--TIG For machines with OKC TIG connection XS12
121 1 0156 867 001 Gas outlet bushing For machines with OKC TIG connection
122 2 0160 362 881 OKC XS13, XS14
123 2 0466 325 001 Gasket For machines with central TIG connection
3 0466 325 001 Gasket For machines with OKC TIG connection
124 1 0457 626 001 Cap
125 1 0538 500 902 Connector socket For machines with OKC TIG connection XS15
126 1 0394 516 005 Spacer
127 1 0486 634 880 Circuit board With connector AP06
2 0193 260 150 Connector 2--pole XA, XD
1 0193 260 153 Connector 5--pole XC
128 1 0366 285 001 Cap
129 1 0366 296 003 Knob
130 1 0301 049 001 Front plate
131 1 0212 602 202 Nut
132 1 0193 307 105 Cable clamp Cable inlet
133 1 0467 696 886 Mains cable
-- 2 0194 034 002 Ferrite ring core To be fitted close to the mains cable inlet L04
134 1 0468 304 001 Rubber seal
135 1 0301 069 883 Panel complete Front panel, circuit board AP05, 13 knobs (items 101,
102 and 103) and 12 locking washers (item 108) are
included. When replacing item 135, item 134 must also
be replaced.
NOTE: This panel does only fit in machines having
processor board AP04 with part no. 0486 770 880.
If the machine has a processor board with part no.
0486 665 880, this must also be replaced.
AP05
1 0193 260 160 Connector 12--pole XA
