ESAB DTE 255 - Page 82

DTE 255
Edition 040621
-- 4 --
dpb1s
C = component designation in the circuit diagram
Item Qty Ordering no. Denomination Notes C
201 1 Cover Replaced by item 202
202 1 0301 075 001 Screening box New design with built--in cover, fits to all
machines
203 2 0162 414 001 Insulating tube
204 1 0301 041 001 Shunt 250 A / 60 mV RS01
205 2 0163 139 001 Bushing
206 1 0193 700 401 Ribbon cable Connectors AP01:XD and AP04:X1/XA are
included
207 1 0486 770 880 Circuit board Replacing circuit board 0486 665 880, fits in all
machines
AP04
1 0193 260 153 Connector 5--pole X4/XD
1 0193 260 155 Connector 7--pole X9/XB
208 1 0486 810 880 Circuit board Replacing circuit board 0486 657 880 AP01
1 0193 260 151 Connector 3--pole XA
1 0193 260 158 Connector 10--pole XB
1 0193 494 003 Ferrite ring core L05
3 0193 260 150 Connector 2--pole XE, XF, XG
1 0193 260 153 Connector 5--pole XI
2 0193 260 152 Connector 4--pole XK, XL
209 1 0301 006 001 Control transformer TC01
210 10 0192 790 103 Spacer
211 1 0301 016 001 Side panel (left)
212 1 0301 017 001 Side panel (right)
213 1 0486 577 880 Circuit board EMC filter AP08
214 1 0366 295 004 Switch QF01
215 1 0301 033 001 Base plate
216 4 0192 562 105 Cage nut M6
217 4 0320 029 002 Ground stud
