DTE 255
Edition 040621
-- 6 --
dpb1s
C = component designation in the circuit diagram
Item Qty Ordering no. Denomination Notes C
301 1 0367 268 001 HF unit AP13
302 1 0486 603 880 IGBT connection Safety circuit boards with connectors AP11, AP12
303 1 0486 613 880 Circuit board IGBT AP02
4 0193 260 150 Connector 2--pole XA, XB, XE,
XF
304 2 0191 085 208 Capacitor 10 ìF, 450 V AC C04, C05
305 1 0365 591 882 Primary inductor L01
306 1 0194 073 001 IGBT module Q5
0192 058 101 Thermal compound For fitting of Q01 -- Q04, Q05 and V07
307 1 Diode module See item 350 V07
308 4 0394 516 031 Spacer screw
309 1 0466 109 001 Fan 230 V AC EV01
310 1 0301 026 880 Secondary inductor L02
311 1 0193 054 002 Solenoid valve 42 V AC YV01
313 2 0467 755 001 Attachment
314 2 0466 895 001 Ferrite core
315 1 0457 841 880 HF coil TV01
316 2 0320 805 887 Capacitor 0.01 ìF, 1000 V C10, C11
317 2 0194 050 001 PTC resistor Thermal sensor ST01, ST03
318 1 0301 007 880 Main transformer Item 320 is included TM01
319 1 0486 607 880 Circuit board Mains rectifier AP03
1 0193 260 153 Connector 5--pole XB
320 4 0193 494 004 Ferrite ring cores Included in TM01 L03
SPARE PARTS SET
Item Ordering no. Denomination Notes
350 0458 920 882 Diode module set Includes item 307 diode module, thermal compound, roller and
mounting instruction.
-- 0458 910 002 Roller handle For the roller in the spare parts set above.
