ESAB DTE 255 - Page 86

DTE 255
Edition 040621
-- 8 --
dpb1s
C = component designation in the circuit diagram
Item Qty Ordering no. Denomination Notes C
401 6 0455 226 004 Spacer
402 1 0486 622 880 Circuit board AP09
2 0193 260 153 Connector 5--pole XA, XB
1 0193 260 155 Connector 7--pole XC
403 1 0486 829 880 Circuit board Replacing circuit board 0486 648 880 AP07
1 0193 260 158 Connector 10--pole XA
1 0193 260 067 Connector 8--pole XB
1 0193 260 153 Connector 5--pole XC
1 0193 260 159 Connector 12--pole XD
404 1 0191 085 208 Capacitor 10 ìF, 450 V AC C09
405 1 0349 061 004 Resistor 120 Ù,80W R03
406 1 0192 579 206 Resistor 1 Ù,50W R05
407 1 0486 628 880 Circuit board AP10
1 0193 260 153 Connector 5--pole XA, XB
408 2 0365 539 001 Fan 230 V AC EV02, EV03
409 1 0194 065 001 Diode V05
410 1 0193 045 011 Terminal block XT23
411 1 0194 050 001 PTC resistor Thermal sensor ST02
412 4 0194 083 001 IGBT module Q01 -- Q04
0192 058 101 Thermal compound For fitting of Q01 -- Q04, Q05 and V07
