C-1
Roller & Wire-Guide Selection
C.1 Roller Selection
ITEM
PART #
DESCRIPTION
COMMENT
FEED ROLLERS FOR ALL WIRES EXCEPT ALUMINUM
1
21155
ROLLER, .024 (.6) - .030 (.8), V-SOLID
OPTIONAL FOR PURCHASE
2
21156
ROLLER, .035 (0.9) - .045 (1.2), V-SOLID
DEFAULT*/ACCESSORY**
3
21157
ROLLER, .052 (1.4) - .062 (1.6), V-SOLID
OPTIONAL FOR PURCHASE
4
21160
ROLLER, .030 (0.8) - .035 (0.9), V-KNURLED
OPTIONAL FOR PURCHASE
5
21161
ROLLER, .045 (1.2) - .052 (1.4), V-KNURLED
ACCESSORY**
FEED ROLLERS FOR ALUMINUM WIRE
6
21159
ROLLER, .045 (1.2) - .062 (1.6), ALUM (U-GROOVE)
OPTIONAL FOR PURCHASE
* DEFAULT (size included in package)
** ACCESSORY (included with each model)
C.2 Wire-Guide Selection
ITEM
#
PART #
DESCRIPTION
COMMENT
OUTPUT WIRE-GUIDE TUBES EXCEPT FOR ALUMINUM WIRE
1
0558 102 585
TUBE, WIRE GUIDE .024 (.6), V-SOLID
OPTIONAL FOR PURCHASE
2
0558 102 584
TUBE, WIRE GUIDE .030 (.8) - .040 (1.0), V-SOLID
ACCESSORY**
3
0558 102 582
TUBE, WIRE GUIDE .035 (0.9) - .045 (1.2), V-SOLID
DEFAULT*
4
0558 102 583
TUBE, WIRE GUIDE .052 (1.4) - .062 (1.6), V-SOLID
ACCESSORY**
OUTPUT WIRE-GUIDE TUBES FOR ALUMINUM WIRE
5
0558 102 586
TUBE, WIRE GUIDE .035 (0.9), ALUM
OPTIONAL FOR PURCHASE
6
0558 102 587
TUBE, WIRE GUIDE .045 (1.2), ALUM
OPTIONAL FOR PURCHASE
7
0558 102 588
TUBE, WIRE GUIDE .052 (1.4) - .062 (1.6), ALUM
OPTIONAL FOR PURCHASE
* DEFAULT (size included in package)
** ACCESSORY (optional size included with each model)
