TECHNICAL SPECIFICATIONS
4-1
SECTION 4 TECHNICAL SPECIFICATIONS
This section lists the specifications for the EMP 285ic (1ph and 3ph) models.
TECHNICAL SPECIFICATION PUBLISHED IN THIS MANUAL:
• Due to variations that can occur in manufactured products, claimed performance,
voltages, ratings, all capabilities, measurements, dimensions and weights quoted are
approximate only. Achievable capacities and ratings in use and operation will depend
upon correct installation, use, applications, maintenance and service.
• The Effective Input Current should be used for the determination of cable size &
supply requirements.
• Motor start fuses, or thermal circuit breakers are recommended for this application.
Check local requirements for your situation in this regard.
• Generator Requirements at the Maximum Output Cycle.
• Due to large variations in performance and specifications of different brands and
types of generators, ESAB cannot guarantee full welding output power or duty cycle
on every brand or type of generator. ESAB recommends that when selecting a
generator, that the power source/generator combination be adequately tested to
ensure the combination performs to the user’s expectations without notice.
4.1 EMP 285ic (1ph) SPECIFICATIONS
Table 4-1. Specifications for EMP 285ic 1ph
SPECIFICATION
230 V ±10%, 1 ph, 50/60 Hz
120 V ±10%, 1 ph, 50/60 Hz
PRIMARY CURRENT
Imax. GMAW - MIG
43.0 A
Breaker 20 A: 28.6 A
Breaker 15 A: 20.3 A
Imax. GTAW - TIG
33.1 A
Breaker 15 A: 20.8 A
Imax. SMAW - Stick
43.6 A
Breaker 15 A: 20.8 A
Ieff. GMAW - MIG
27.2 A
Breaker 20 A: 18.0 A
Breaker 15 A: 14.6 A
Ieff. GTAW - TIG
18.2 A
Breaker 15 A: 14.7 A
Ieff. SMAW - Stick
27.6 A
Breaker 15 A: 14.7 A
PERMISSIBLE LOAD AT GMAW - MIG
100% duty cycle*
160A (V
out
= 22V)
Breaker 15A: 75A (V
out
=
17.75V)
Breaker 20A: 90A (V
out
=
18.5V)
