ESAB EMP 285ic 3ph User Manual

MAINTENANCE
8-5
8.3 EMP-UNIT POWER-SIDE MAINTENANCE
8.4 TORCH LINER MAINTENANCE
Refer to MIG torch instruction manual for replacing standard steel torch conduit liner with a
Teflon torch conduit liner.
• Model EMP 285ic 1ph uses torch model: Spray Master Velocity 250V
• Model EMP 285ic 3ph uses torch model: Spray Master Velocity 350V
8.4.1 TORCH LINER CLEANING
1. Disconnect the power source from the input power socket.
2. Disconnect the torch assembly from the unit
3. Remove the wire from the torch wire-liner by pulling the wire out from the torch wire-
liner and laying it neatly for re-installation at the end of this procedure.
4. Remove the liner from the torch hose and inspect it for damage or kinks. Clean the
liner by blowing compressed air (max. 5 bar) through the end of the liner that was
mounted closest to the unit.
5. Re-install the liner.
6. Re-install the wire through the Wire-Feed Assembly until visible at the torch tip. Verify that
the wire does correctly feed out of the torch.
NOTE
There are no user-serviceable parts on the Power-Side.
In dusty environments, the Power-Side should be
checked periodically for any dust/debris accumulation
because of the fan forced-air cooling used on this side.
Because of the electro-static sensitive components and
exposed circuit boards any maintenance on this side
should be done by an authorized ESAB service
technician.
