ESAB EMP 285ic 3ph - Page 52

OPERATION
6-11
Figure 6-14. Plotting Duty Cycle for 120 V, 1ph AC
Figure 6-15. Plotting Duty Cycle for 230 V, 1ph AC
0
10
20
30
40
50
60
70
80
90
100
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140
Duty Cycle %
Welding Current (Amps)
Duty cycle on 120V AC
MIG@20A
MIG@15A
MMA
TIG
0
10
20
30
40
50
60
70
80
90
100
100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300
Duty Cycle %
Welding Current (Amps)
Duty cycle on 230V AC
TIG
MMA
MIG
