OPERATION
6-22
5. ADJUSTING FOR CORRECT ROLLER PRESSURE:
If you hold the welding torch approximately 2 in. (50 mm) from the piece of
wood, the wire should be fed out and bend (Figure 6-24).
Figure 6-24. Checking for Proper Feed-Roller Pressure
2 inches
HARD WOOD
SURFACE
