Monitor Address
The multicast address used by the client and server when the monitoring
type is multicast. If broadcasting is used, this address does not need to be
configured, and the system will communicate by default usi
ng the broadcast
address of the device's wan port IP
Remote Port
Fill in a custom hotspot communication port. The server and client ports
need to be consistent
Name Fill in the name of the SIP hotspot. This configuration is used to identify
different hotspots on the network to avoid connection conflicts
Line Settings
Sets whether to enable the SIP hotspot function on the corresponding SIP
line
Client Settings:
As a SIP hotspot client, there is no need to set up a SIP account, which is automatically acquired and
configured when the device is enabled. Just change the mode to "client" and the other options are set
in the same way as the hotspot.
The device is the hotspot server, and the default extension is 0. The device ACTS as a client, and the
extension number is increased from 1 (the extension number can be viewed through the “SIP hotspot”
webpage).
Calling internal extension:
• The hotspot server and client can dial each other (example: extension 1 dials extension 0)
