Page #6 background imageLoading...
Page #6 background image
Page 6 of 66 0455-0323 Rev A
Installation
Use PoE or external Power Adapter
The ESI AC64v supports two power supply modes, power supply from external power adapter or
Power over Ethernet (PoE) compliant switch.
PoE power supply saves the space and cost of providing the device additional power outlet. With a
PoE switch, the device can be powered through a single Ethernet cable which is also used for data
transmission. By attaching UPS to PoE switch, the device can keep working at power outage just like
traditional PSTN telephone which is powered by the telephone line.
For users who do not have PoE equipment, the traditional power adaptor should be used. If the
device is connected to a PoE switch and power adapter at the same time, the power adapter will be
used in priority and will switch to PoE power supply once it fails.
Use a quality power adapter or a PoE switch that meets standard PoE specifications to ensure proper
function.
IP Address Reporting
Action behavior
Description
Standby report IP In standby mode, long press the speed dial button for 3 seconds, there
will be a 5 second tone. Press the speed dial button once within 5
seconds. The tone will stop automatically then announce IP.
Press the button in the upper right corner .
Switch network mode
In the standby mode, long-press the speed dial button for 3 seconds
and
the beep will last for 5 seconds. Within 5 seconds, press the speed
dial button three times quickly to switch to the network mode.
If there is no IP at present, switch to the default static IP
(192.168.1.128).
Then switch to DHCP mode when it is the default static IP
(192.168.1.128)
When DHCP gets to IP, then do not switch and report the IP directly.
Report the IP after the successful switch
Voice loop mode
After you press the speed dial button twice, the device enters the voice
loopback mode. After you press the MIC speaker, you can check the
voice related problems. After you press the speed dial button again,
you can exit the voice loopback mode
LED status
Indicator status
Meaning
Steady green
Standby (No registration, normal network)
Steady cyan
Registration success
Cyan light flash
talking/Calling/going
Red slow flash
Registration failed
Red slow flash
Network anomaly
Orange light flash
Upgrade and restore factory
Steady
Standby
Flashing 1s
A credit card
